Seica Rapid V4 Flying Needle Light Plate Tester

The answer to those who require both high efficiency and multifunctional vertical flying probe testing systems can be found on the Rapid V4 tester, which is equipped with 4 independent moving probes (2 on each side), suitable for checking the internal dynamic characteristics of PCB boards. Based on the simplicity of Seica's VIP platform and VIVA software, the training time is very short, and operators do not require special skills. The Rapid V4 flying needle tester is suitable for every customer, such as small manufacturers, R&D laboratories, service and R&D laboratories, certification and quality assurance enterprises.

characteristic

It can test the internal structural layers of boards, ceramic boards, flexible boards, and printed boards

4-pin independent flying needle system

Two CCD cameras for identifying upper and lower reference points

Test area of 540mm x 610mm (21 ″ x 24 ″)

High voltage, high impedance insulation test

Vacuum suction cup (optional)

High precision probes for small solder pads and precision spaced solder pads

High speed testing

Embedded repair workstation

Touch screen function

ICT testing of embedded components

Seica VIVA software
